The structure of the LED display includes those parts

source:Industry News release time:2023.07.04 Hits:1     Popular:led screen wholesaler

Share:

The structure of the LED display includes the following parts:

LED module: The LED module is the core part of the LED display, which can arrange the LED lamp beads on the circuit board according to certain rules, and control the LED lamp beads through the driving circuit.

Circuit board: The circuit board is the supporting part of the LED display, mainly composed of power supply circuit, control circuit, signal transmission circuit and so on.

1 (3)

Mask: The mask is the shell part of the LED display, which can protect the LED lamp beads and make the LED display more beautiful.

Bracket: The bracket is the supporting part of the LED display, which can fix the LED display in the designated position.

Data line and power line: The data line and power line are the parts that connect the LED display with computers, monitors and other equipment, and can transmit the data and power of the LED display.

The structure of the LED display is very important, which directly affects the performance and service life of the LED display. When using the LED display, pay attention to protecting the LED display, and carry out regular maintenance and inspection.
